CAT 226B SKID STEER LOADER MJH Operation and Maintenance Manual Page 303

Operation and Maintenance Manual

Page of 331

/ 331

Product: SKID STEER LOADER

Model: 226B SKID STEER LOADER MJH

Configuration: 216B 226B 232B 242B Skid Steer Loader MJH00001-10574

(MACHINE) POWERED BY 3024C Engine

Operation and Maintenance Manual

216B, 226B, 232B, 236B, 242B, 246B, 248B, 252B, 262B and 268B Skid Steer Loaders

Media Number -SEBU7731-08 Publication Date -01/07/2007 Date Updated -16/07/2007

i01970036

Seat Belt - Replace

SMCS - 7327-510

Within three years of the date of installation (2) or within five years of the date of manufacture (1), replace

the seat belt. Replace the seat belt at the date which occurs first. A date label for determining the age of

the seat belt is attached to each seat belt.

Illustration 1 g01022746

(1) Date of Manufacture

(2) Date of Installation

Contact your Caterpillar dealer for the replacement of the seat belt.
