CAT 226B SKID STEER LOADER MJH Operation and Maintenance Manual Page 72

Operation and Maintenance Manual
252B R.O.C NR 1164 kg (2566 lb)
1157 kg (2551 lb)
262B R.O.C NR 1164 kg (2566 lb)
1157 kg (2551 lb)
268B R.O.C 1172 kg (2584 lb)
1164 kg (2566 lb)
1157 kg (2551 lb)
216B and 226B (B)
612 mm (2.0 ft) 612 mm (2.0 ft)
NR
232B (B)
781 mm (2.6 ft) 781 mm (2.6 ft) 782 mm (2.6 ft)
242B (B)
747 mm (2.5 ft) 747 mm (2.5 ft) 748 mm (2.5 ft)
236B, 246B and 248B
(B)
599 mm (2.0 ft) 599 mm (2.0 ft) 599 mm (2.0 ft)
252B, 262B and 268B
(B)
861 mm (2.8 ft) 861 mm (2.8 ft) 861 mm (2.8 ft)
216B, 226B, 228B (A)
2114 mm (6.9 ft) 2114 mm (6.9 ft) 2114 mm (6.9 ft)
232B (A)
2265 mm (7.4 ft) 2264 mm (7.4 ft) 2263 mm (7.4 ft)
242B (A)
2303 mm (7.6 ft) 2303 mm (7.6 ft) 2302 mm (7.6 ft)
236B, 246B and 248B
(A)
2338 mm (7.7 ft) 2338 mm (7.7 ft) 2338 mm (7.7 ft)
252B, 262B and 268B
(A)
2427 mm (8.0 ft) 2427 mm (8.0 ft) 2427 mm (8.0 ft)
( 1 )
The rated capacity is calculated with a full bucket of dirt. Grasping objects with the grapple will lower the rated capacity.
( 2 )
Machines that are equipped with High Flow Hydraulics
Table 8
Utility Grapple Buckets
(1)
Part Number 165-8729 165-8730
Width
1676 mm (66 inch) 1829 mm (72 inch)
Bucket Weight
330 kg (727 lb) 344 kg (758 lb)
Models
71
71
