Discoloration

Cuts on the insulation of the cable

Fouling

Corroded terminals, damaged terminals, and loose terminals

Replace damaged battery cable(s) and replace any related parts. Eliminate any fouling, which may have

caused insulation failure or related component damage or wear. Ensure that all components are reinstalled

correctly.

An exposed wire on the battery cable may cause a short to ground if the exposed area comes into contact

with a grounded surface. A battery cable short produces heat from the battery current, which may be a fire

hazard.

An exposed wire on the ground cable between the battery and the disconnect switch may cause the

disconnect switch to be bypassed if the exposed area comes into contact with a grounded surface. This

may result in an unsafe condition for servicing the machine. Repair components or replace components

before servicing the machine.

Fire on a machine can result in personal injury or death.

Exposed battery cables that come into contact with a

grounded connection can result in fires. Replace cables and

related parts that show signs of wear or damage. Contact

your Caterpillar dealer.

Wiring

Check electrical wires daily. If any of the following conditions exist, replace parts before you operate the

machine.

Fraying

Signs of abrasion or wear

Cracking

Discoloration

Cuts on insulation

Other damage

Make sure that all clamps, guards, clips, and straps are reinstalled correctly. This will help to prevent

vibration, rubbing against other parts, and excessive heat during machine operation.

Attaching electrical wiring to hoses and tubes that contain flammable fluids or combustible fluids should be

avoided.

Consult your Caterpillar dealer for repair or for replacement parts.
