CAT 226B SKID STEER LOADER MJH Operation and Maintenance Manual Page 183

Operation and Maintenance Manual
Product: SKID STEER LOADER
Model: 226B SKID STEER LOADER MJH
Configuration: 216B 226B 232B 242B Skid Steer Loader MJH00001-10574
(MACHINE) POWERED BY 3024C Engine
Operation and Maintenance Manual
216B, 226B, 232B, 236B, 242B, 246B, 248B, 252B, 262B and 268B Skid Steer Loaders
Media Number -SEBU7731-08 Publication Date -01/07/2007 Date Updated -16/07/2007
i01961474
Towing the Machine
SMCS - 7000
If the machine is disabled, the machine should be lifted onto a trailer in order to be transported. Refer to
Operation and Maintenance Manual, "Lifting and Tying Down the Machine" for the lifting procedure.
Retrieval of Machine
If the machine cannot be lifted, use the following guidelines in order to retrieve the machine.
Illustration 1 g01019061
Shutdown SIS
