switch. This will disable the hydraulic

functions. Press the top of the switch again

in order to activate the hydraulic functions.

Note: Activate the hydraulic shutoff when you are roading the machine in order to prevent unplanned

movement of the work tool and the loader arms.

Interlock Override - The interlock

override allows the auxiliary hydraulic

circuits to function with the armrest in the

RAISED position. First activate the

continuous flow control that is located on

the left side joystick. Refer to the section

"Joystick and Auxiliary Hydraulic Controls"

for detailed information. Press the bottom

of the interlock override switch. This will

activate the interlock override function. In

order to turn off the interlock override and

continuous flow, press the bottom of the

switch again.

NOTICE

Do not leave the machine unattended while you have the

interlock override function activated.

A switch is provided on the cab door that prevents implement operations when the cab door is open. If you

choose to operate without the cab door, you must install a jumper wire between Terminal 4 and Terminal 5

in the wiring harness connector for the Window Wiper. Refer to Special Instruction, REHS1738, "Installing

the Cab Door and Mounting Group" for more information about the cab door.

Note: When the door is installed, remove the jumper wire from the connector plug before you connect the

harness. Damage to the door could occur if the jumper is left in place.

Beacon Switch (8)
