The retractor will adjust the belt length and the retractor will lock in place. The comfort ride sleeve will

allow the operator to have limited movement.

Releasing The Seat Belt

Illustration 7 g00039113

Push the release button on the buckle in order to release the seat belt. The seat belt will automatically

retract into the retractor.

Extension of the Seat Belt

When using retractable seat belts, do not use seat belt

extensions, or personal injury or death can result.

The retractor system may or may not lock up depending on

the length of the extension and the size of the person. If the

retractor does not lock up, the seat belt will not retain the

person.

Longer, non-retractable seat belts and extensions for the non-retractable seat belts are available.

Caterpillar requires only non-retractable seat belts to be used with a seat belt extension.

Consult your Caterpillar dealer for longer seat belts and for information on extending the seat belts.

Private Network For SIS Licensees.

Sat Jan 28 2012 03:59:35 GMT-0800 ( ( ))
