CAT 226B SKID STEER LOADER MJH Operation and Maintenance Manual Page 108

Operation and Maintenance Manual

Page of 331

/ 331

Product: SKID STEER LOADER

Model: 226B SKID STEER LOADER MJH

Configuration: 216B 226B 232B 242B Skid Steer Loader MJH00001-10574

(MACHINE) POWERED BY 3024C Engine

Operation and Maintenance Manual

216B, 226B, 232B, 236B, 242B, 246B, 248B, 252B, 262B and 268B Skid Steer Loaders

Media Number -SEBU7731-08 Publication Date -01/07/2007 Date Updated -16/07/2007

i02696055

Operator Controls

SMCS - 7300; 7451

Note: Your machine may not be equipped with all of the controls that are discussed in this topic.

Note: Your machine may be equipped with a Dedicated Dual Direction Control Kit. The Dedicated Dual

Direction Control Kit changes the control of the work tool and the movement of the machine. The other

functions of the joysticks are not affected by the Dedicated Dual Direction Control Kit. Refer to the topic

Dedicated Dual Direction Control Kit for details.

Note: Simple hydromechanical work tools may be shipped without hydraulic oil. Uneven movement may

occur until all the air has been removed from the work tool. You may need to add hydraulic oil to the

machine after the machine fills the circuits of the work tool. Refer to Operation and Maintenance Manual,

"Hydraulic System Oil Level - Check" for the proper procedure for checking the hydraulic oil level.

Note: If the machine is not equipped with a cab that is enclosed, Caterpillar recommends the use of a

flying object guard. If the machine is equipped with an enclosed cab, operate the machine with the cab

door in the CLOSED position.

Shutdown SIS

Previous Screen

107
