Operation and Maintenance Manual

216B, 226B, 232B, 236B, 242B, 246B, 248B, 252B, 262B and 268B Skid Steer Loaders

Media Number -SEBU7731-08 Publication Date -01/07/2007 Date Updated -16/07/2007

i01992184

Stopping the Engine

SMCS - 1000; 7000

NOTICE

Stopping the engine immediately after it has been working

under load, can result in overheating and accelerated wear

of the engine components.

Refer to the following procedure, to allow the engine to

cool, and to prevent excessive temperatures in the

turbocharger housing (if equipped), which could cause oil

coking problems.

1. Operate the engine for five minutes at low idle with no load.

Note: This allows hot areas in the engine to cool gradually. This will extend the engine life.

2. Move the joysticks into the HOLD position.

3. Turn the engine start switch key to the OFF position.

4. Relieve the pressure in the auxiliary hydraulic system. Refer to Operation and Maintenance Manual,

"Work Tool Coupler Operation" for details.

5. Ensure that the engine start switch key is in the OFF position after the pressure in the auxiliary

hydraulic system has been relieved.

6. Cover the exhaust opening after the machine has cooled down.
