four seconds and release the switch.

Note: The pressure in the secondary circuit is not affected by this switch.

Note: The operator must remain in the seat with the armrest in the LOWERED position in order for

the control to function.

4. Move the engine start switch to the OFF position.

Secondary Auxiliary Circuit

The pressure in the secondary circuit is released with the following procedure:

If electrical power is available and the accumulator is charged, the pressure can be released from the

operator station with the work tool control.

1. Fasten the seat belt. Lower the armrest.

2. Turn the engine start switch key to the ON position.

3. Release the parking brake.

4. Activate the controls for the secondary auxiliary function. Activate the controls several times in order

to release all the pressure. Refer to Operation and Maintenance Manual, "Auxiliary Hydraulic Controls"

for information about the controls.

If the pressure is not released, the accumulator is not charged. It is possible to recharge the accumulator

by running the engine or cranking the engine for a period of fifteen seconds. Repeat step 3 and 4.
