CAT 226B SKID STEER LOADER MJH Operation and Maintenance Manual Page 214

Operation and Maintenance Manual

Page of 331

/ 331

Product: SKID STEER LOADER

Model: 226B SKID STEER LOADER MJH

Configuration: 216B 226B 232B 242B Skid Steer Loader MJH00001-10574

(MACHINE) POWERED BY 3024C Engine

Operation and Maintenance Manual

216B, 226B, 232B, 236B, 242B, 246B, 248B, 252B, 262B and 268B Skid Steer Loaders

Media Number -SEBU7731-08 Publication Date -01/07/2007 Date Updated -16/07/2007

i00993589

Battery - Recycle

SMCS - 1401-561

Always recycle a battery. Never discard a battery.

Always return used batteries to one of the following locations:

A battery supplier

An authorized battery collection facility

Recycling facility

Private Network For SIS Licensees.

Sat Jan 28 2012 04:24:31 GMT-0800 ( ( ))

Shutdown SIS

Previous Screen

213
