Controls". Connect the wiring harness to the electrical plug (1) .

Note: If your High Flow work tool does not have a wiring harness, a Jumper Plug needs to be installed on

the electrical plug (1) for the work tool control. Without this Jumper Plug, the machine will not provide High

Flow to the work tool. Please refer to your Parts Manual for the current part number for the Jumper Plug.

The affected machines are in the following list:

226B High Flow

242B High Flow

248B (XPS)

268B (XPS)

257B High Flow

287B (XPS)

Simple Hydromechanical Work Tools

Work tools in the following table are approved by Caterpillar. Refer to Operation and Maintenance Manual,

"Joystick and Auxiliary Hydraulic Controls" for the location and operation of the joystick controls that are

referenced in the table.

Please read the manual and understand the instructions and warnings in the Operation and Maintenance

Manual for these work tools. Consult your Caterpillar dealer for replacement manuals. Proper care is your

responsibility.

Table 1

Operation of Caterpillar Simple Hydromechanical Work Tools

Work Tool Joystick Control Actions

Multipurpose

Bucket

The bucket clam closes.

The bucket clam opens.

All Grapple

tools

The grapple closes.

The grapple opens.

Angle Blade

The blade angles to the left.

The blade angles to the right.

Dozer Blade

The blade angles to the left.

162
