CAT 226B SKID STEER LOADER MJH Operation and Maintenance Manual Page 258

Operation and Maintenance Manual
Product: SKID STEER LOADER
Model: 226B SKID STEER LOADER MJH
Configuration: 216B 226B 232B 242B Skid Steer Loader MJH00001-10574
(MACHINE) POWERED BY 3024C Engine
Operation and Maintenance Manual
216B, 226B, 232B, 236B, 242B, 246B, 248B, 252B, 262B and 268B Skid Steer Loaders
Media Number -SEBU7731-08 Publication Date -01/07/2007 Date Updated -16/07/2007
i02811482
Engine Oil and Filter - Change
SMCS - 1308-510; 1348-044
S/N - BXM1-4224
S/N - MJH1-10574
S/N - RLL1-6799
S/N - SCH1-2474
NOTICE
Care must be taken to ensure that fluids are contained
during performance of inspection, maintenance, testing,
adjusting and repair of the product. Be prepared to collect
the fluid with suitable containers before opening any
compartment or disassembling any component containing
fluids.
Refer to Special Publication, NENG2500, "Caterpillar Dealer
Service Tool Catalog" for tools and supplies suitable to
collect and contain fluids on Caterpillar products.
Dispose of all fluids according to local regulations and
mandates.
The normal oil change interval for the machine is Every 250 Service Hours or every year when the following
conditions are met:
Caterpillar oil, API Specification CI-4, CH-4 or CG-4 multigrade oil is used.
Caterpillar filters are used.
The altitude does not exceed 2300 m (7545 ft).
Sulfur content in the fuel is between 0.05% and 0.50%.
Shutdown SIS
Previous Screen
257
257
Previous page
Next page
