Product: SKID STEER LOADER

Model: 226B SKID STEER LOADER MJH

Configuration: 216B 226B 232B 242B Skid Steer Loader MJH00001-10574

(MACHINE) POWERED BY 3024C Engine

Operation and Maintenance Manual

216B, 226B, 232B, 236B, 242B, 246B, 248B, 252B, 262B and 268B Skid Steer Loaders

Media Number -SEBU7731-08 Publication Date -01/07/2007 Date Updated -16/07/2007

i02401142

Lubricant Viscosities

SMCS - 7581

The proper oil viscosity grade is determined by the minimum outside temperature when the machine is

started. The proper oil viscosity grade is also determined by the maximum outside temperature while the

machine is operated. Use the column that has the title of "Min" on the table to determine the oil viscosity

grade that is required for starting a cold machine. Use the column that has the title of "Max" on the table

to determine the oil viscosity grade for operating the machine at the highest temperature that is

anticipated. Use the oil with the highest viscosity that is allowed for the ambient temperature when you

start the machine.

Machines that are continuously operated should use the oils with the higher viscosity in the final drives and

differentials in order to maintain the highest possible oil film thickness. Consult your Caterpillar dealer if

additional information is needed.

Table 1

Lubricant Viscosities for Ambient Temperatures

Compartment or System

Oil Type and

Classification

Oil Viscosities

°C °F

Min

Max

Min

Max

Engine Crankcase for all

Machines

(1)

(2)

and Drive Chain Boxes

Cat DEO Multigrade

Cat DEO SYN

Cat Arctic DEO

SYN

(3)

Cat ECF-1

(4)

API CG-4

Multigrade

(5)

SAE 0W-20

-40

SAE 0W-30 -40 30

-40

SAE 0W-40 -40 40

-40

104

SAE 5W-30 -30 30

-22

SAE 5W-40 -30 50

-22

122

SAE 10W-30

(6)

-18 40 0

104

Shutdown SIS

Previous Screen

203
