7. Release the glow plug switch momentarily.

8. Turn the engine start switch key to the START position in order to start the engine. Press the glow

plug switch and hold the switch during engine cranking in order to assist starting. Release the keyand

release the glow plug switch after the engine has started.

9. Run the engine for 5 minutes. The engine should run smoothly at low idle. The engine should run

smoothly as speed is gradually increased to high idle. Allow the white smoke to disperse before you

proceed with normal operation.

10. Disengage the parking brake.

11. Run the engine at half throttle. Hold the work tool control in the TILT BACK position for thirty

seconds. Release the control for thirty seconds. Hold the work tool control in the LOWER position for

thirty seconds. Release the control for thirty seconds. Perform the procedure for three minutes.

Note: If you are operating the machine below 0 °C (32 °F), perform the procedure for eight minutes.

NOTICE

Do not use the hydraulic interlock override function to

warm up the machine.

12. Keep all personnel away from the machine. Move the machine very slowly to an open area. Repeat

Step 11 as you move the machine back and forth for 3 m (10 ft).

Note: More warm up time may be required if the hydraulic functions are sluggish.

Private Network For SIS Licensees.

Sat Jan 28 2012 03:59:39 GMT-0800 ( ( ))

135
