CAT 226B SKID STEER LOADER MJH Operation and Maintenance Manual Page 206

Operation and Maintenance Manual
Product: SKID STEER LOADER
Model: 226B SKID STEER LOADER MJH
Configuration: 216B 226B 232B 242B Skid Steer Loader MJH00001-10574
(MACHINE) POWERED BY 3024C Engine
Operation and Maintenance Manual
216B, 226B, 232B, 236B, 242B, 246B, 248B, 252B, 262B and 268B Skid Steer Loaders
Media Number -SEBU7731-08 Publication Date -01/07/2007 Date Updated -16/07/2007
i02019812
Capacities (Refill)
SMCS - 7560
Table 1
Approximate Refill Capacities
216B, 226B, 232B and 242B Machines
Compartment or System Liters US Gallons Imperial Gallons
Engine Crankcase
3024
7.5 2.0 1.6
Hydraulic Tank 35.0 9.3 7.7
Cooling System
216B and 232B
9.0 2.4 2.0
Cooling System
226B and 242B
10.5 2.8 2.3
Fuel Tank
216B and 226B
65.0 17.2 14.3
Fuel Tank
232B and 242B
69.0 18.2 15.2
Each Drive Chain Box
216B and 226B
6.0 1.6 1.3
Each Drive Chain Box
232B and 242B
8.0 2.1 1.8
Table 2
Approximate Refill Capacities
236B, 246B, 248B, 252B, 262B and 268B Machines
Compartment or System Liters US Gallons Imperial Gallons
Engine Crankcase
3044
9.0 2.4 2.0
Shutdown SIS
Previous Screen
205
205
