CAT 226B SKID STEER LOADER MJH Operation and Maintenance Manual Page 210

Operation and Maintenance Manual

Page of 331

/ 331

Product: SKID STEER LOADER

Model: 226B SKID STEER LOADER MJH

Configuration: 216B 226B 232B 242B Skid Steer Loader MJH00001-10574

(MACHINE) POWERED BY 3024C Engine

Operation and Maintenance Manual

216B, 226B, 232B, 236B, 242B, 246B, 248B, 252B, 262B and 268B Skid Steer Loaders

Media Number -SEBU7731-08 Publication Date -01/07/2007 Date Updated -16/07/2007

i02743768

Maintenance Interval Schedule

SMCS - 7000

S/N - BXM1-4224

S/N - MJH1-10574

S/N - RLL1-6799

S/N - SCH1-2474

When Required

Battery - Recycle

Battery or Battery Cable - Inspect/Replace

Blade Frame - Adjust

Bucket Cutting Edges - Inspect/Replace

Bucket Tips - Inspect/Replace

Cab Air Filter - Clean/Replace

Circuit Breakers and Fuses - Reset/Replace

Engine Air Filter Primary Element - Clean/Replace

Engine Air Filter Secondary Element - Replace

Fuel System Priming Pump - Operate

Fuel Tank Cap - Clean

Fuel Tank Water and Sediment - Drain

Lower Machine Frame - Clean

Oil Filter - Inspect

Tire Segment - Replace

Window Washer Reservoir - Fill

Window Wiper - Inspect/Replace

Windows - Clean

Every 10 Service Hours or Daily

Backup Alarm - Test

Cooling System Level - Check

Engine Oil Level - Check

Fuel System Primary Filter (Water Separator) - Drain

Hydraulic System Oil Level - Check

Shutdown SIS

Previous Screen
