CAT 226B SKID STEER LOADER MJH Operation and Maintenance Manual Page 297

Operation and Maintenance Manual

Page of 331

/ 331

Product: SKID STEER LOADER

Model: 226B SKID STEER LOADER MJH

Configuration: 216B 226B 232B 242B Skid Steer Loader MJH00001-10574

(MACHINE) POWERED BY 3024C Engine

Operation and Maintenance Manual

216B, 226B, 232B, 236B, 242B, 246B, 248B, 252B, 262B and 268B Skid Steer Loaders

Media Number -SEBU7731-08 Publication Date -01/07/2007 Date Updated -16/07/2007

i01968724

Refrigerant Dryer - Replace - If Equipped

SMCS - 7322-510

Personal injury can result from contact with refrigerant.

Contact with refrigerant can cause frost bite. Keep face and

hands away to help prevent injury.

Protective goggles must always be worn when refrigerant

lines are opened, even if the gauges indicate the system is

empty of refrigerant.

Always use precaution when a fitting is removed. Slowly

loosen the fitting. If the system is still under pressure,

release it slowly in a well ventilated area.

Personal injury or death can result from inhaling refrigerant

through a lit cigarette.

Inhaling air conditioner refrigerant gas through a lit

cigarette or other smoking method or inhaling fumes

released from a flame contacting air conditioner refrigerant

gas, can cause bodily harm or death.

Do not smoke when servicing air conditioners or wherever

refrigerant gas may be present.

Use a certified recovery and recycling cart to properly

remove the refrigerant from the air conditioning system.

NOTICE

If the refrigerant system has been open to the outside air

(without being plugged) for more than 30 minutes, the

receiver-dryer must be replaced. Moisture will enter an

Shutdown SIS

Previous Screen

296
