CAT 226B SKID STEER LOADER MJH Operation and Maintenance Manual Page 115

Operation and Maintenance Manual
Parking Brake Control - Press on the
right side of the switch in order to engage
or disengage the parking brake.
Note: The parking brake will engage when the engine is stopped. The parking brake will engage when the
armrest is moved to the RAISED position. The parking brake will engage when the operator leaves the
operator seat for an extended period of time.
Auxiliary Hydraulic Mode (12)
NOTICE
High flow should not be continuously operated on
machines that are equipped with high flow hydraulics. The
high flow can be operated continuously on machines that
are equipped with high flow and high pressure hydraulics.
Note: High flow will not operate if rabbit mode has been selected with the two speed control. High flow
mode also requires an electrical connection that is located on the loader arm. Refer to Operation and
Maintenance Manual, "Work Tool Coupler Operation" or Operation and Maintenance Manual, "Work Tool
Operation" for additional details.
Connect the work tool harness to the electrical plug on the loader arm.
Note: If your High Flow work tool does not have a wiring harness, a Jumper Plug needs to be installed on
the electrical plug for the work tool control. Without this Jumper Plug, the machine will not provide High
Flow to the work tool. Please refer to your Parts Manual for the current part number for the Jumper Plug.
Auxiliary Hydraulic Mode - Press the
right side of the switch in order to select
high flow. The indicator light will illuminate.
Move the thumb wheel that is located on
the right side joystick in order to supply
hydraulic oil flow to the auxiliary hydraulic
lines. Press the left side of the switch in
order to select standard flow. The indicator
light will not be illuminated. Move the thumb
wheel that is located on the right side
joystick in order to supply hydraulic oil flow
to the auxiliary hydraulic lines. Refer to the
section "Joystick and Auxiliary Hydraulic
Controls" for additional details.
Note: The thumb wheel must be moved to full displacement in order to achieve maximum pressure and
flow for the following models: 248B, 268B and 287B High Flow.
Service Hour Meter (13)
Service Hour Meter - The service hour
114
114
