C27 and C32 Generator Sets Engines Disassembly and Assembly Page 17

Disassembly and Assembly
RENR9716-02 17
Disassembly and Assembly Section
i02287744
Turbocharger - Rem ove
SMCS Code: 1052
-011
Removal Proced
ure
NOTICE
Care must be tak
en to ensure that fluids are contained
during performance of inspection, maintenance, test-
ing, adjusting and repair of the product. Be prepared to
collect the flu
id with suitable containers before open-
ing any compartment or disassembling any compo-
nent containing fluids.
Refer to Special Publication, NENG2500, “Caterpillar
Tools and Shop Products Guide” for tools and supplies
suitable to co
llect and contain fluids on Caterpillar
products.
Dispose of al
l fluids according to local regulations and
mandates.
NOTICE
Keep all parts clean from contaminants.
Contaminants may cause rapid wear and shortened
component life.
1. Drain the coolant from the cooling system into a
suitable con
tainer for storage or disposal. Refer
to Operation and Maintenance Manual, “Cooling
System Coolant - Change”.
g01145002
Illustration 47
g01148173
Illustration 48
2. Remove tube assembly (2).
3. Disconnect tube assemblies (1) and tube
assembly (4).
4. Attach a suitable lifting device to turbocharger (5).
The weight of turbocharger (5) is approximately
45 kg (100 lb).
5. Remove nuts (3). Remove turbocharger (5) and
the gasket.
i02287870
Turbocharger - Disassemb le
SMCS Code: 1
052-015
Disassemb
ly Procedu re
Start By:
a. Remove the turbocharger. Refer to Disassembly
and Assembly, “Turbocharger - Remove”.
NOTICE
Keep all parts clean from contaminants.
Contamina
nts may cause rapid wear and shortened
component life.
