Caterpillar 3516B and 3516B High Displacement Engines for Caterpillar Built Machines Troubleshooting Page 81

Troubleshooting
RENR5622 81
Troubleshooting Section
Table 28
Diagnostic Codes Table
Description
Conditions wh
ich Generate this Code
System Respon
se
MID 0036 - CID 0168 - FMI 01 System
Voltage Low
The battery supply voltage is less than
9 VDC for two seconds.
The engine’s ECM has been powered
for three seconds.
The engine is not being cranked.
MID 0036 - CID 0168 - FMI 02 Battery
Voltage intermittent/erratic
The engine is running. The battery
voltage fall
s below 9 VDC for at least
.06 seconds. The voltage returns above
9 VDC.
or
Three voltage readings in the last seven
seconds were below 9 VDC.
The code is logged if the engine is
running.
Use this test when there are active occurrences or
logged occurrences of diagnostic codes. Use this
test if there are intermittent engine shutdowns or if
a difficulty in starting is not accompanied by loss of
electrical accessories. Engine shutdowns that are
accompanied by a loss of other electrical accessories
indicate a problem in the keyswitch. This does not
indicateaprobleminthewiringattheECM.Verify
that there are no problems with the starting system or
with the charging system before you use this test.
There are two +Battery connections and two −Battery
connections to the ECM. These multiple lines will
reduce the resistance at the harness. The ECM
continuously receives battery voltage through a 15
amp breaker. When the ECM senses the battery
voltage at the keyswitch input, the ECM turns on.
When the voltage is removed from the keyswitch
input, the ECM turns off.
