Caterpillar 3516B and 3516B High Displacement Engines for Caterpillar Built Machines Troubleshooting Page 124

Troubleshooting
124 RENR5622
Troubleshooting Section
Results:
•
OK – The harness is OK. Proceed to Test Step 3.
•
Not OK – There is
damage to the harness.
Repair: Repair the wires or replace the wires,
as required. V
erify that the repair eliminates the
problem.
STOP.
Test Step 3. Inspect the Connector
Terminals
A. Visually inspect each terminal in the connector.
Verify that the terminals are not damaged.
Verify that t
he terminals are properly aligned in
the connector and verify that the terminals are
properly located in the connector.
Expected Result:
The terminal
s are properly aligned and the terminals
appear undamaged.
Results:
•
OK – The terminals are OK. Proceed to Test Step
4.
•
Not OK – The terminals of the connector are
damaged.
Repair: Repair the terminals and/or replace the
terminals,
as required.
Verify that the repair eliminates the problem.
STOP.
Test Step 4.
Perform a Pull Test on Each
Wire Termi
nal Connection
g01131435
Illustra
tion 52
Receptacle lock wedge (typical example)
A. Ensure that the locking wedge for the connector
is installed pr
operly. Terminals cannot be retained
inside the connector if the locking wedge is not
installed properly.
B. Perform the 45 N (10 lb) pull test on each wire.
Each terminal and each connector should easily
withstand 45
N (10 lb) of tension and each wire
should remain in the connector body. This test
checks whether the wire was properly crimped
in the termin
al and whether the terminal was
properly inserted into the connector.
Expected Res
ult:
Each terminal and each connector easily withstands
45 N (10 lb) of
pull and each wire remains in the
connector body.
Results:
•
OK – All terminals pass the pull test. Proceed to
Test Step 5.
•
Not OK – A wire has been pulled from a terminal
or a termina
l has been pulled from the connector.
Repair: Use the 1U-5804 Crimp Tool to replace
the termina
l. Replace damaged connectors, as
required. Verify that the repair eliminates the
problem.
STOP.
Test Step 5
. Check Individual Pin
Retentio
n into the Socket
g01131604
Illustr
ation 53
Diagram for testing pin retention (typical example)
A. Verify that the sockets provide good retention for
thepins.Insertanewpinintoeachsocketone
at a time
in order to check for a good grip on the
pin by the socket.
