Caterpillar 3516B and 3516B High Displacement Engines for Caterpillar Built Machines Troubleshooting Page 113

Troubleshooting
RENR5622 113
Troubleshooting Section
Table 36
Diagnostic Codes Table
Description
Conditions wh
ich Generate this Code
System Respon
se
MID 0036 - CID 0001 - FMI 05 Cylinder
#1 Injector open circuit
The engine’s Electronic Control Module
(ECM) detects an open circuit.
The code is logged.
The ECM continues to fire the injector
solenoid.
MID 0036 - CID 0001 - FMI 06 Cylinder
#1 Injector short
The ECM detects a short circuit. The code is lo
gged.
The ECM will disable the solenoid
circuit. The ECM will periodically try
to fire the in
jector. If the short circuit
remains, this sequence of events will be
repeated until the problem is corrected.
MID 0036 - CID 0002 - FMI 05 Cylinder
#2 Injector open circuit
The engine’s ECM detects an open
circuit.
The code is logged.
The ECM continues to fire the injector
solenoid.
MID 0036 - CID 0002 - FMI 06 Cylinder
#2 Injector short
The ECM detects a short circuit.
The code is logged.
The ECM will d
isable the solenoid
circuit. The ECM will periodically try
to fire the injector. If the short circuit
remains, th
is sequence of events will be
repeated until the problem is corrected.
MID 0036 - CID 0003 - FMI 05 Cylinder
#3 Injector open circuit
The engine’s ECM detects an open
circuit.
The code is logged.
The ECM continues to fire the injector
solenoid.
MID 0036 - CID 0003 - FMI 06 Cylinder
#3 Injector short
The ECM detects a short circuit.
The code is logged.
The ECM will disable the solenoid
circuit. Th
e ECM will periodically try
to fire the injector. If the short circuit
remains, this sequence of events will be
repeated u
ntil the problem is corrected.
MID 0036 - CID 0004 - FMI 05 Cylinder
#4 Injector open circuit
The engine’s ECM detects an open
circuit.
The code is logged.
The ECM continues to fire the injector
solenoid.
MID 0036 - CID 0004 - FMI 06 Cylinder
#4 Injector short
The ECM detects a short circuit. The code i
s logged.
The ECM will disable the solenoid
circuit. The ECM will periodically try
to fire th
e injector. If the short circuit
remains, this sequence of events will be
repeated until the problem is corrected.
MID 0036 - CID 0005 - FMI 05 Cylinder
#5 Injector open circuit
The engine’s ECM detects an open
circuit.
The code is logged.
The ECM continues to fire the injector
solenoid.
MID 0036 - CID 0005 - FMI 06 Cylinder
#5 Injector short
The ECM detects a short circuit.
The code is logged.
The ECM wi
ll disable the solenoid
circuit. The ECM will periodically try
to fire the injector. If the short circuit
remains
, this sequence of events will be
repeated until the problem is corrected.
MID 0036 - CID 0006 - FMI 05 Cylinder
#6 Injector open circuit
The engine’s ECM detects an open
circuit.
The code is logged.
The ECM continues to fire the injector
solenoid.
MID 0036 - CID 0006 - FMI 06 Cylinder
#6 Injector short
The ECM detects a short circuit.
The code is logged.
The ECM will disable the solenoid
circuit
. The ECM will periodically try
to fire the injector. If the short circuit
remains, this sequence of events will be
repeat
ed until the problem is corrected.
(continued)
