Caterpillar 3516B and 3516B High Displacement Engines for Caterpillar Built Machines Troubleshooting Page 26

Troubleshooting
26 RENR5622
Troubleshooting Section
g01210600
Illustrat
ion 1 3
Low oil pressure map
Default Co nditions for the
Monitori ng System
Table8co
ntains the default conditions that cause an
event code to be generated. Table 8 also contains a
column that describes the system response when
the cond
itions indicate that an abnormal operating
condition exists.
Table 8
Default Conditions and System Response
Event Co
de
Conditi
ons which Generate this Code
System R
esponse
E017 High Engine Coolant Temperature
Warning
The engine coolant temperature is
above the trip point temperature for five
seconds.
Thecodeisactiveandthecodeis
logged.
E021 Hi
gh Exhaust Temperature Derate
The exh
aust temperature is above the
trip point temperature for five seconds.
The cod
eisactiveandthecodeis
logged.
The ramp rate of the derate is 2 percent
per 15 s
econds.
The maximum derate is 20 percent.
E035 Loss of Coolant Flow Warning The coolant flow switch opens.
Thecodeisactiveandthecodeis
logged.
E038 Low Engine Coolant Temperature
Warning
The co
olant temperature is below the
trip point temperature for five seconds.
The co
de is active and the code is
logged.
(continued)
