C27 and C32 Generator Sets Operation and Maintenance Manual Page 91

Operation and Maintenance Manual
SEBU8088-06 91
Maintenance Section
Cooling System Supplemental Coolant Additive (SCA) - Test/Add
Cooling Systems that Us e
Conventional Coolant
This maintenance procedure is required for
conventional coolants such as DEAC.This
maintenance is NOT required for cooling systems
that are filled with Extended Life Coolant.
Test the Concentration of the SCA
NOTICE
Do not exceed the recommended six percent supple-
mental coolant additive concentration.
Test t h e co nc
entration of the SCA with the 8T-5296
Coolant Conditioner Test Kit.
Add the SCA, I
f Necessary
Pressurized System: Hot coolant can cause seri-
ous burns. To open the cooling system filler cap,
stop the engine a nd wait until the cooling system
components are cool. Loosen the cooling system
pressure cap slowly in order to relieve the pres-
sure.
1. Remove the cooling system filler cap slowly.
2. If necessary, drain some coolant in order to allow
spacefortheadditionoftheSCA.
3. Add the proper amount of SCA. For the
proper amount of SCA, refer to this Operation
and Maintenance Manual, “Refill Capacities
and Recommendations” topic. The proper
concentration of SCA depends on the type of
coolant that is used. For the proper concentration
of SCA, refer to Special Publication, SEBU6251,
“Caterpillar Commercial Diesel Engine Fluids
Recommendations”.
4. Clean the cooling system filler cap. Install the
cooling system filler cap.
Cooling Systems th at Use Water
and S CA
Test the Concentration o f the SCA
Test the concentration of the SCA with a 298-5311
Coolant Nitrite Test Kit for SCA or perform an S·O·S
Coolant Analysis. The test kit includes the following
items: a tool for the testing, 30 ampoules for testing
nitrite, instructions, and a case. 294-7420 Te s t
Kit contains the refill ampoules for the 298-5311
Coolant Nitrite Test Kit. Use the instructions that are
included with the test kit in order to properly conduct
the testing.
Refer to this Operation and Maintenance Manual,
“Maintenance Interval Schedule” for the times at
which the procedures should be conducted. Test the
concentration of the SCA more frequently if more
frequent testing is indicated by the results of the
S·O·S Coolant Analysis.
NOTICE
Do not exceed the recommended eight percent sup-
plemental coolant additive concentration.
Add the SCA, If Necessary
Pressurized System: Hot coolant can cause seri-
ous burns. To open the cooling system filler cap,
stop the engine and wait until the cooling system
components are cool. Loosen the cooling system
pressure cap slowly in order to relieve the pres-
sure.
1. Remove the cooling system filler cap slowly.
2. If necessary, drain some coolant in order to allow
space for the addition of the SCA.
3. Add the proper amount of SCA. For the proper
amount of SCA, refer to this Operation and
Maintenance Manual, “Refill Capacities and
Recommendations” topic. For the proper
concentration of SCA, refer to Special Publication,
SEBU6251, “Caterpillar Commercial Diesel
Engine Fluids Recommendations”.
4. Clean the cooling system fi ller cap. Install the
cooling system filler cap.
