C27 and C32 Generator Sets Operation and Maintenance Manual Page 11

Operation and Maintenance Manual
SEBU8088-06 11
Safety Section
Safety Messages
Lifting the Genset (4)
This safety message for lifting the genset is located
on right, left, and rear panels of the generator
enclosure.
g01433231
Crushing Hazard! Improper l ifting could cause se-
rious injury or dea th. Follow the lifting instruc-
tions in t
he Operation and Maintenance Manual for
safe lifting procedures.
Hot Fluid Under Pressure (5)
The safety message for hot fluid under pressure is
located on top of the radiator near the radiator cap.
g01371640
Pressurized system! Hot coolant can cause seri-
ous burns, injury or death. To open the cooling
system filler ca p, stop the engine and wait until
the cooling system components are c ool. Loosen
the cooling system pressure cap slowly in order to
relieve the pressure. Read and understand the Op-
eration and Maintenance Manual be fore perform-
ing any cooling system maintenance.
Electrical Shock (6)
The safety message for electrical shock is located on
the sides of the terminal box.
g01372247
WARNING! Shock/Electrocution Hazard! Read and
unders
tand the i nstructions and warnings in the
Operation and M aintenance Manual. Failure to fol-
low the instructions or heed the warnings could
cause
serious injury or death.
