C27 and C32 Generator Sets Operation and Maintenance Manual Page 10

Operation and Maintenance Manual
10 SEBU8088-06
Safety Section
Safety Messages
Universal Warning (1)
The universal safety message is located on each
side of the generator enclosure and on each side of
the terminal box.
g01370904
Do not operate or work on this product unless you
have read and understand the instructions and
warnings in the Operation and Maintenance Man-
ual. Failure to follow the instructions or heed the
warnings could result in injury or death. Contact
any Caterpillar dealer for replacement manuals.
Proper ca re is your r esponsibility.
Automatic S tarting (2)
The safety message for automatic starting is located
on each side of the enclosure.
g01392484
When the engine is in the AUTOMATIC mode, the
engine
can start at any moment. To avoid personal
injury, always remain clear of the the engine when
the engine is in the AUTOMATIC mode.
Hot Surface (3)
These safety messages are located on each side
of the radiator and on each side of the b arrel of the
generator.
g01384734
Hot parts or hot components can cause burns or
personal injury. Do not allow hot parts or c ompo-
nents to c
ontact your skin. Use protective clothing
or protective equipment to protect your skin.
