C27 and C32 Generator Sets Operation and Maintenance Manual Page 12

Operation and Maintenance Manual
12 SEBU8088-06
Safety Section
General Hazard Information
i02574315
General Hazard Information
SMCS Code: 1000; 4450; 7405
g00104545
Illustration 5
Attach a “Do Not Operate” warning tag or a similar
warning tag to the start switch or to the controls
before the e
ngine is serviced or before the engine is
repaired. These warning tags (Special Instruction,
SEHS7332) are available from your Caterpillar
dealer. Att
ach the warning tags to the engine and to
each operator control station. When it is appropriate,
disconnect the starting controls.
Do not allow unauthorized personnel on the engine,
or around the engine when the engine is being
serviced.
Engine exhaust contains products of combustion
which may b
e harmful to your health. Always start the
engine and operate the engine in a well ventilated
area. If the engine is in an enclosed area, vent the
engine ex
haust to the outside.
Cautiously remove the following parts. To help
prevent s
praying or splashing of pressurized fluids,
hold a rag over the part that is being removed.
•
Filler ca
ps
•
Grease fittings
•
Pressure taps
•
Breather
s
•
Drain plugs
Use caution when cover plates are removed.
Gradually loosen, but do not remove the last two
bolts or
nuts that are located at opposite ends of
the cover plate or the device. Before removing the
last two bolts or nuts, pry the cover loose in order to
relieve
any spring pressure or other pressure.
g00702020
Illustration 6
•
Wear a hard hat, protective glasses, and other
protective equipment, as required.
•
When work is performed around an engine that is
operating, wear protective devices for ears in order
to help prevent damage to hearing.
•
Do not wear loose clothing or jewelry that can snag
on controls or on other parts of the engine.
•
Ensure that all protective guards and all covers are
securedinplaceontheengine.
•
Never put maintenance fluids into glass containers.
Glass containers can break.
•
Use all cleaning solutions with care.
•
Report all necessary repairs.
Unless other instructions are provided, perform
the maintenance under the following conditions:
•
The engine is stopped. Ensure that the engine
cannot be started.
•
Disconnect the batteries when maintenance
is performed or when the electrical system is
serviced. Disconnect the battery ground leads.
Tape the leads in order to help prevent sparks.
•
Disconnect the connector for the unit injector that
is located on the valve cover base. This will help
prevent personal injury from the high voltage to the
unit injectors. Do not come in contact with the unit
injector terminals while the engine is operating.
•
Do not attempt any repairs that are not understood.
Use the proper tools. Replace any equipment that
is damaged or repair the equipment.
