Cooling System Coolant (ELC) - Change

i02056152

Coo ling System Coolant (ELC)

- Change

SMCS Code: 1350-044-NL

Clean the cooling system and ﬂush the cooling

system before the recommended maintenance

interval if th

e following conditions exist:

•

The engine overheats frequently.

•

Foaming is observed.

•

The oil has ent

ered the cooling system and the

coolant is contaminated.

•

The fuel has en

tered the cooling system and the

coolant is contaminated.

Note: When th

e cooling system is cleaned, only

clean water is needed when the ELC is drained and

replaced.

Note: Inspect the water pump and the water

temperature regulator after the cooling system has

been draine

d. This is a good opportunity to replace

the water pump, the water temperature regulator and

the hoses, if necessary.

Drain

Pressurized System: Hot coolant can cause seri-

ous burns. To open the cooling system ﬁller cap,

stop the en

gine and wait until the cooling system

components are cool. Loosen the cooling system

pressure cap slowly in order to relieve the pres-

sure.

1. Stop the engine and allow the engine to cool.

Loosen the

cooling system ﬁller cap slowly in

order to relieve any pressure. Remove the cooling

system ﬁller cap.

2. Open the cooling system drain valve (if equipped).

If the cooling system is not equipped with a drain

valve, re

move the cooling system drain plugs.

Allow the coolant to drain.

NOTICE

Dispose o

f used engine coolant properly or recycle.

Various methods have been proposed to reclaim used

coolant for reuse in engine cooling systems. The full

distilla

tion procedure is the only method acceptable by

Caterpillartoreclaimtheusedcoolant.

For informatio

n regarding the disposal and the

recycling of used coolant, consult your Caterpillar

dealerorconsultCaterpillarDealerServiceTool

Group:

Outside Illinois: 1-800-542-TOOL

Inside Illino

is: 1-800-541-TOOL

Canada: 1-800-523-TOOL

Flush

1. Flush the cool

ingsystemwithcleanwaterinorder

to remove any debris.

2. Close the drai

n valve (if equipped). Clean the

drain plugs. Install the drain plugs. Refer to

the Speciﬁcations Manual, SENR3130, “Torque

Speciﬁcatio

ns” for more information on the proper

torques.

NOTICE

Fill the cooling system no faster than 19 L (5 US gal)

per minute to avoid air locks.

3. Fill the cooling system with clean water. Install the

cooling sys

tem ﬁller cap.

4. Start and run the engine at low idle until the

temperatur

e reaches 49 to 66 °C (120 to 150 °F).

5. Stop the engine and allow the engine to cool.

Loosen the c

ooling system ﬁller cap slowly

in order to relieve any pressure. Remove the

cooling system ﬁller cap. Open the drain valve

(if equipp

ed) or remove the cooling system drain

plugs. Allow the water to drain. Flush the cooling

system with clean water. Close the drain valve

(if equipp

ed). Clean the drain plugs. Install the

drain plugs. Refer to the Speciﬁcations Manual,

SENR3130, “Torque Speciﬁcations” for more

informat

ion on the proper torques.

Fill

NOTICE

Fill the cooling system no faster than 19 L (5 US gal)

per minute to avoid air locks.

1. Fill the c

ooling system with Extended Life Coolant

(ELC). Refer to the Operation and Maintenance

Manual, “Reﬁll Capacities and Recommendations”

topic (Ma

intenance Section) for more information

on cooling system speciﬁcations. Do not install the

cooling system ﬁller cap.

2. Start and run the engine at low idle. Increase the

engine rpm to high idle. Run the engine at high

idle for

one minute in order to purge the air from

the cavities of the engine block. Stop the engine.
