C27 and C32 Generator Sets Operation and Maintenance Manual Page 108

Operation and Maintenance Manual
108 SEBU8088-06
Maintenance Section
Insulation - Test
Duetoextremet
emperature changes, the hose will
heat set. Heat setting causes hose clamps to loosen.
This can result in leaks. A constant torque hose
clamp will hel
ptopreventloosehoseclamps.
Each installation application can be different. The
differences
depend on the following factors:
•
Type of hose
•
Type of fitting material
•
Anticipated
expansion and contraction of the hose
•
Anticipated expansion and contraction of the
fittings
Replace the H
oses and the Clamps
Pressurized System: Hot coolant can cause seri-
ous burns. To open the cooling system filler cap,
stop the engine a nd wait until the cooling system
components are cool. Loosen the cooling system
pressure cap slowly in order to relieve the pres-
sure.
1. Stop the engine. Allow the engine to cool.
2. Loosen the cooling system filler cap slowly in
order to relieve any pressure. Remove the cooling
system filler cap.
Note: Drain the coolant into a suitable, clean
container. The coolant can be reused.
3. Drain the coolant from the cooling system to a
level that is below the hose that is being replaced.
4. Remove the hose clamps.
5. Disconnect the old hose.
6. Replace the old hose with a new hose.
7. Install the hose clamps with a torque wrench.
Note: Refer to the Specifications, SENR3130,
“Torque Specifications” in order to locate the proper
torques.
8. Refill the cooling system.
9. Clean the cooling system filler cap. Inspect the
cooling system filler cap’s gaskets. Replace
the cooling system fi ller cap if the gaskets are
damaged. Install the cooling system filler cap.
10. Start the engin
e. Inspect the cooling system for
leaks.
i01494696
Insulation - Test
SMCS Code: 445
3-081; 4454-081; 4457-081;
4470-081
Recommended Periodic Insulation
Tests
The high voltage that is produced by an operating
generator se
t can cause severe injury or death.
Before performing any maintenance or repairs,
ensure that the generator will not start.
Place the engine control switch in the “OFF” posi-
tion. Attach “DO NOT OPERATE” tags to all start-
ing control
s. Disconnect the batteries or disable
the starting system. Loc k out all switchgear and
automatic transfer switches that are associated
with the gen
erator.
Table 12
Tools Needed
Part Number Part Name Quantity
142-5055
Insulation
Testin g Gp
1
9U-6003
Insulation
Testin g Gp
1
Periodically, use an insulation tester to check the
insulation resistance of the generator’s main stator
winding. The frequency of this test is determined by
the generator’s environment. Previous insulation
tester readings will also determine the frequency of
this test.
Test the main stator windings with an insulation tester
in the following situations:
•
The generator set is started for the fi rst time.
•
The generator set is removed from storage.
•
The generator set is operating in a humid
environment. Test every three months.
•
The generator set is not protected from the
elements in an enclosed area. Test every three
months.
