SEBU8088-06 103

Maintenance Section

Fuel Tank Water and Sediment - Drain

5. Install the new

fuel ﬁlter. Spin the fuel ﬁlter onto

the fuel ﬁlter base until the gasket contacts the

base. Use the rotation index marks on the ﬁlters

as a guide for p

roper tightening. Tighten the

ﬁlter for an additional 3/4 turn by hand. Do not

overtighten the ﬁlter.

i03071053

Fuel Tank Water and Sediment

-Drain

SMCS Code: 1273-543-M&S

NOTICE

Care must be t

aken to ensure that ﬂuids are contained

during performance of inspection, maintenance, test-

ing, adjusting and repair of the product. Be prepared to

collect the

ﬂuid with suitable containers before open-

ing any compartment or disassembling any compo-

nent containing ﬂuids.

Refer to Special Publication, NENG2500, “Caterpillar

Dealer Service Tool Catalog” or refer to Special Pub-

lication,

PECJ0003, “Caterpillar Shop Supplies and

Tools Catalog” for tools and supplies suitable to col-

lect and contain ﬂuids on Caterpillar products.

Dispose of all ﬂuids according to local regulations and

mandates.

Fuel Tank

Fuel quali

ty is critical to the performance and to the

service life of the engine. Water in the fuel can cause

excessive wear to the fuel system. Condensation

occurs du

ring the heating and cooling of fuel. The

condensation occurs as the fuel passes through the

fuel system and the fuel returns to the fuel tank. This

causes wa

ter to accumulate in fuel tanks. Draining

the fuel tank regularly and obtaining fuel from reliable

sources can help to eliminate water in the fuel.

Drain the Water and the S ediment

Fuel tanks should contain some provision for draining

water and draining sediment from the bottom of the

fuel tan

ks.

Open the drain valve on the bottom of the fuel tank

in order

to drain the water and the sediment. Close

the drain valve.

Check t

he fuel daily. Drain the water and sediment

from the fuel tank after operating the engine or drain

the water and sediment from the fuel tank after the

fuel ta

nk has been ﬁlled. Allow ﬁve to ten minutes

before performing this procedure.

Fill the fuel ta

nk after operating the engine in

order to drive out moist air. This will help prevent

condensation. Do not ﬁll the tank to the top. The

fuel expands a

s the fuel gets warm. The tank may

overﬂow .

Some fuel tan

ks use supply pipes that allow water

and sediment to settle below the end of the fuel

supply pipe. Some fuel tanks use supply lines that

take fuel dir

ectly from the bottom of the tank. If

the engine is equipped with this system, regular

maintenance of the fuel system ﬁ lter is important.

Fuel Storage Tanks

Drain the water and the sediment from the fuel

storage tank during the following conditions:

•

Weekly

•

Oil change

•

Reﬁll of the tank

This will help prevent water or sediment from being

pumped from the storage tank into the engine fuel

tank. A four

micron(c) absolute ﬁlter for the breather

vent on the fuel tank is also recommended. Refer

to Special Publication, SENR9620, “Improving Fuel

System Dur

ablity”.

If a bulk storage tank has been reﬁlled or moved

recently,

allow adequate time for the sediment to

settle before ﬁlling the engine fuel tank. Internal

bafﬂes in the bulk storage tank will also help trap

sediment

. Filtering fuel that is pumped from the

storage tank helps to ensure the quality of the fuel.

When possible, water separators should be used.

i02290310

Generator - Dry

SMCS Cod

e: 4450-569

NOTICE

Do not operate the generator if the windings are wet. If

the generator is operated when the windings are wet,

damage c

an occur due to insulation breakdown.

When moisture is present or when moisture is

suspect

ed in a generator, the generator must be

dried before being energized.

If the dr

ying procedure does not restore the insulation

resistance to an acceptable value, the winding should

be reconditioned.

Note: For additional information, refer to Special

Instruction, SEHS9124 .
