Programming Cat Electronic Truck Engine Page 98

Programming
Page 97
Emissions Parameters
Data Link ARD Disable Status
Description:
This parameter allows a technician to disable
a regeneration from occurring for service or
troubleshooting. A diagnostic code will be Active
and the Amber Warning Lamp illuminated while this
parameter is programmed to Disabled.
Note: If the key power is cycled from off to on the
Aftertreatment Regeneration Device Manual Disable
parameter will not go back to its default value of Not
Disabled (Regeneration will be disabled).
Available:
EPA’07 and newer C7, C9, C13 & C15 on-highway engines
Range:
Engine Range
Cat
Default
EPA’07 and newer C7,
C9, C13 & C15
Disabled
Not Disabled
Not Disabled
Advantages:
Allows the service techinician a convenient method
to disable the Caterpillar Regeneration System during
servicing.
Disadvantages:
Technician must reprogram this setting to Not Disabled
before returning the vehicle to normal operation in order
for the Caterpillar Regeneration System to function
normally.
Recommendations:
✔This parameter should only be used by a qualifi ed
service technician in conjunction with the
diagnosing and repair of the engine.
