Programming Cat Electronic Truck Engine Page 66

Programming
Page 65
Dedicated PTO Parameters
PTO Cab Controls RPM Limit
(ALSO KNOWS AS “ PTO CAB THROTTLE RPM LIMIT”)
Description:
The PTO Cab Controls RPM Limit determines the engine
RPM limit of the Cab Accelerator Pedal Position Sensor
and Cab Set/Resume Switch when PTO Confi guration
is programmed to Cab Switches and the PTO On/Off
circuit is ON. This parameter is intended to prevent the
engine from overspeeding the PTO system while using
dedicated PTO.
• If Programmed to
Low Idle, the Cab Throttle Position
Sensor is ignored.
• If programmed to TEL, the engine will operate to the
programmed Top Engine Limit.
• If Programmed to PTO TEL, the engine will operate
to the programmed PTO Top Engine Limit.
Note: PTO Confi guration must be programmed to Cab
Switches for this parameter to take effect. If PTO
Confi guration is programmed to Remote Switches,
Remote Throttle or Remote Throttle & J1939 Speed
Command the ECM will always ignore the Cab Controls
when PTO mode is active.
Available:
All electronically controlled on-highway engines
covered in this handbook
Range:
Range Cat Default
Low Idle
TEL
PTO TEL
TEL
Advantages:
Prevents the use of the cab throttle to override PTO
settings and overspeeding the PTO device.
Disadvantages:
None
Recommendations:
✔ Refer to RENR1282 for more specifi c details.
