Timer Parameters
Engine Retarder Delay
Description:
The Engine Retarder Delay parameter provides a
programmable delay to assist shifting of some European
transmissions. The delay occurs after the basic retarder
conditions have been met.
Available:
C-10, C-12, C-15, C-16, C11, C13, C15 heavy duty and
EPA’07 and newer C7 & C9 engines
Range:
Engine
Range
Cat
Default
Minimum Maximum
C-10, C-12, C-15,
C-16, C11, C13, C15,
EPA’07 and newer
C7 & C9
0 seconds 3 seconds 0 seconds
Advantages:
Allows the use of a wider range of transmissions.
Disadvantages:
None
Recommendations:
✔ Engine Retarder Delay should be programmed to
zero except when required by the transmission.
