Idle Parameters

Fast Idle Engine RPM #1 & #2

Description:

With the installation of a momentary contact Fast Idle

switch, the driver can toggle the switch and the engine

will go immediately to a preset RPM value.

The available RPM values are stored as the Fast Idle

Engine RPM #1 or Fast Idle Engine RPM #2 parameters.

The ranges for these two parameters are listed below.

The engine will increase from the programmed Low Idle

to the Fast Idle Engine RPM #1 value when the Fast Idle

switch is ﬁ rst pressed and released. The second time

the Fast Idle switch is pressed and released, the engine

will increase to the Fast Idle Engine RPM #2 value. After

pressing the Fast Idle switch a third time, the engine will

return to low idle, and Fast Idle will be disabled.

The difference between the Fast Idle Engine RPM #1

and #2 parameters is that the #1 parameter can be

overridden by the operator, whereas the #2 parameter

cannot be overridden beyond the programmed value.

To override the Fast Idle Engine RPM #1 parameter, the

operator should press the accelerator pedal until the

desired rpm is reached, and then depress the Fast Idle

Enable switch. This rpm will then be the Fast Idle Engine

RPM #1 value as long as the ECM is powered.

Available:

Pre EPA’07: 3126E, C7, and C9 medium duty engines

EPA’07: All On-Highway Engine Platforms

Range:

Engine

Fast Idle

Engine

RPM #

Range

Cat

Default

Minimum Maximum

3126E, C7,

1 700 RPM TEL RPM 1000 RPM

2 700 RPM TEL RPM 0 RPM

2007 C13,

C15

1 600 RPM TEL RPM 1000 RPM

2 600 RPM TEL RPM 0 RPM

Advantages:

Setting the Fast Idle Engine RPM can help reduce work

cycle time by reducing the time it takes to get the engine

up to the preferred RPM.

Recommendations:

✔ This programmable feature is application

dependent and should be programmed based on

customer speciﬁ c requirements.
