Engine Monitoring Lamps
Low Oil Pressure Lamp
OEM
Description:
The Low Oil Pressure Lamp is used to indicate a low oil
pressure condition. The Low Oil Pressure Lamp default
is not programmed. The Low Oil Pressure Lamp can be
used in conjunction with other engine monitoring lamp
options. The Low Oil Pressure Lamp is programmable to
other ECM outputs.
Note: The Low Oil Pressure Lamp is programmable
between High Side (2 Amp) and Low Side (Sensor
Common) Drivers. Failure to properly program and/or
wire the lamp correctly could result in undesired Red
Stop Lamp operation.
Available:
3126E, C7, C9 and all EPA’07 and newer on-highway
engines
Range:
Engine Range Cat Default
EPA’07
and newer
C7, C9,
C13 & C15
High Side Drivers
(2 Amp Output)
J1/P1: 10, 11, 12, 13, 19, 20
Not
Programmed
Los Side Drivers
(Sensor Common)
J1/P1: 29, 30, 31
Note: Prior to 2007, the Low Oil Pressure Lamp connection was
determined by the option chosen for the Engine Monitoring Lamps
confi guration.
Pre-2007 Factory Settings:
Engine Range Cat Default
GM530/540 None None
GMT560
None
Installed
Installed
Other
None
Installed
None
Advantages:
This parameter provides the operator with engine oil
pressure information via a vehicle instrument cluster oil
pressure gauge, enabling the operator to more closely
monitor the engine oil pressure status.
