Programming Cat Electronic Truck Engine Page 167

Programming
Page 166
Fan Override Switch /
OEM
/
Description:
The Fan Override Switch parameter is programmed
to identify the Fan Override Switch connection to the
ECM. This parameter can be programmed to one of the
available hard wired options or J1939 datalink source
inputs. The switch itself allows the operator to turn
on the cooling fan at any time, resulting in improved
retarding/braking and engine cooling.
Available:
All electronically programmable on-highway engines
covered in this handbook
Range:
Engine Range
Cat
Default
3126E, C7, C9
J1939 Cab Controller, J1939
Body Controller, J1939 Instru-
ment Cluster
None
C-10, C-12, C-15, C-16,
C11, C13, C15
J1/P1:6, J1/P1:7, J1/P1:46,
J1/P1:47, J1939 Cab Controller,
J1939 Body Controller, J1939
Instrument Cluster*
None
EPA’07 and newer
C7, C9
None
J1/P1: 6, 7, 22, 23, 35, 40, 44, 45,
46, 47, 56, 58, 59, 60
Or
J1939 Body Controller
J1939 Cab Controller
J1939 Instrument Cluster
None
EPA’07 and newer
C13, C15
None
J1/P1: 6, 7, 22, 23, 35, 40, 44, 45,
46, 47, 56, 58, 59, 60
Or
J1939 Body Controller
J1939 Cab Controller
J1939 Insturment Cluster
J1939 Cab Display
None
*Note: J1939 alternatives NOT available on PM OCT01 heavy-duty
engines (C-10, C-12, C-15, C-16)
Advantages:
When programmed to one of the input Alternatives, this
parameter allows the use of the Fan Override Switch,
which results in improved engine retarding/braking and
engine cooling.
Input Selection
