Programming Cat Electronic Truck Engine Page 165

Programming
Page 164
Input Selection
• Exhaust Brake Switch
• Fan Override Switch
• Transmission Neutral Switch
• Torque Limit Switch
• Ignore Brake/Clutch Switch
• Two-Speed Axle Switch
• Diagnostic Enable Switch
• PTO On/Off Switch
• PTO Engine Shutdown Switch
• PTO Engine RPM Set Speed Input A
• PTO Engine RPM Set Speed Input B
• Remote PTO Set Switch
• Remote PTO Resume Switch
• Cruise Control On/Off Switch
• Cruise Control Set/Resume Switch
• Cruise Control Pause Switch
• A/C High Pressure Switch
• A/C Fan Request Switch
• Vehicle Speed Input
• Service Brake Pedal Position Switch #1
• Service Brake Pedal Position Switch #2
• Starting Aid On/Off Switch
• Parking Brake Switch
• Clutch Pedal Position Switch
• Retarder Off/Low/Med/High Switch
• Fast Idle Enable Switch
• ARD Disable Switch Confi g
• ARD Force Switch Confi g
• Air Inlet Shutoff Switch Confi g
• Air Inlet Shutoff Threshold Reduction Switch
• ARD Soft Shutdown Input Confi guration
• Engine Shutdown Override Switch
Note that Input Selections are not designated as
Factory, OEM Databook, or Optional. These selections
are all, in effect, optional, but are typically set at
the factory. However, after the vehicle is shipped,
various inputs can be added either by the customer or
OEM. The Input Selections section has been added
for completeness due to its direct relation with the
parameters discussed in this handbook.
