Programming Cat Electronic Truck Engine Page 91

Programming
Page 90
Min/Max Governor with Speed Control
The Min/Max Governor with Speed Control offers the
best combination of the Full Range Governor and the
Min/Max Governor. It provides smooth shifting with
automatic/automated transmissions while driving,
and precise engine speed control when the vehicle is
parked.
Available:
All electronically controlled on-highway engines
covered in this handbook (Note: Excludes C-10, C-12,
C-15, C-16 PM OCT01)
Range:
Engine Range Cat Default
3126E, C7, C9
(PM MAR03 and before)
C-10, C-12, C-15, C-16
(PM JAN02 - PM OCT02)
Min/Max
Full Range
Full Range
3126E, C7, C9
(PM MAR 04 and after)
C11, C13, C15
Min Max
Min/Max with
Speed Control
Full Range
Full Range
Advantages:
The Governor Type parameter allows the operator
to customize engine speed control by specifying the
appropriate governor for the selected transmission
type. When the Governor Type is properly set as
recommended below, optimum engine speed control is
achieved.
Disadvantages:
None
Recommendations:
✔ The Full Range Governor is recommended for
vehicles with manual transmissions.
✔ The Min/Max Governor is recommended for
vehicles with automatic/automated transmissions.
✔ The Min/Max Governor with Speed Control
is recommended for all automatic/automated
transmission-equipped vehicles with that require
precise engine speed control when parked.
Engine/Gear Parameters
