Programming Cat Electronic Truck Engine Page 233

Programming
Page 232
Trip Data
Custom Data
Description:
The ECM provides 5 user defi nable Custom Data
Reports. These can be programmed using a service tool
or Fleet Information Software (FIS). Custom Data is part
of the Fleet Trip Data. When the Fleet Trip Data is reset
the Custom Data is also reset.
The basic program is: Sum (column 1) For (column 2)
Between (column 3) And (column 3) And (column 2) Between
(column 3) and (column 3).
Column 1 Column 2 Column 3
Engine Hours or
Distance Trav-
eled (Miles or
kilometers) or
Fuel Used (Gal-
lons or Liters)
or Occurrences
(number of times
and event has
occurred)
Engine RPM 0 - 3,000
Vehcile Speed (MPH or
km/h)
0 - 127
(0 - 205)
Fuel Rate (gallons/hr or
liters/hr)
0 - 40
(0 - 150)
Percent Load 0 - 100
Coolant Temp. °F (°C)
0 - 248
(0 - 120)
Oil Pressure psi (kPa)
0 - 100
( 0 - 689)
Fuel Temperature °F (°C)
0 - 248
(0 - 120)
Intake Manifold Air Temp
°F (°C)
0 - 248
(0 - 120)
Cruise Control
Active/
Not Active
PTO Control
Active/
Not Active
Engine Brake Solenoids
Active/
Not Active
Percent Throttle 0 - 100
Service Brakes On/Off
Example:
To fi nd the number of gallons of fuel used when the
truck was traveling between 55 and 65 MPH.
Sum
Gallons for MPH between 55 and 65
This would store the number of gallons of fuel used
during the current Fleet Trip Segment when the truck
was traveling between 55 and 65 MPH.
Available:
All electronically controlled on-highway engines
covered in this handbook
