Programming Cat Electronic Truck Engine Page 230

Programming
Page 229
Trip Data
Fleet Trip Totals
Description:
The ECM can store certain information in a Fleet Trip
Total. The length of this data is user dependent. The
Fleet Trip Reset can be performed by a service tool,
Fleet Information Software (FIS) or the Caterpillar
Driver Information Display Cat ID or Cat Messenger, if
programmed to do so (see page
This information includes:
• Time (Engine Hours) • % PTO Time
• Driving Time • Average Load Factor
• Distance • Average Vehicle Speed
• Fuel • Average Driving Speed
• Overall Fuel Economy • Maximum Vehicle Speed
• Driving Fuel Economy • Maximum Engine Speed
• Idle Time • Start Time
• Idle Fuel • End Time
• % Idle Time • Start Odometer
• PTO Time • End Odometer
• PTO Fuel
Available:
All electronically controlled on-highway engines cov-
ered in this handbook
237).
