Dedicated PTO Parameters
PTO to Set Speed
Description:
When the PTO to Set Speed parameter is programmed
to Yes, the engine rpm will go directly to the value
programmed in the PTO Engine RPM Set Speed
parameter (see page ) when Dedicated PTO is On. PTO
Confi guration must be programmed to Cab Switches
or Remote Switches before this parameter can be
programmed.
Note: This parameter is not available if PTO
Confi guration is programmed to Remote Throttle or
Remote Throttle & J1939 Speed Command.
Available:
All electronically controlled on-highway engines
covered in this handbook.
Range:
Range Cat Default
No
Yes
No
Advantages:
By automatically going to a programmed engine RPM
every time Dedicated PTO is engaged, cycle time can be
reduced and precise control of engine rpm is possible
for specialized PTO applications.
Disadvantages:
None
Recommendations:
✔ Set the PTO to Set Speed Parameter to YES if the
application requires the engine to go to a specifi ed
RPM every time the Dedicated PTO feature is On.
✔ For further details, refer to RENR1282.
