Low Speed Range Axle Ratio

OEM

High Speed Range Axle Ratio

OEM

FORMERLY: NOMINAL AXLE RATIO - HIGH SPEED RANGE AXLE RATIO

TWO-SPEED AXLE - LOW SPEED RANGE AXLE RATIO

Description:

These two parameters must be programmed when a

Two-Speed Axle On/Off Switch is used by the ECM in

order to adjust the vehicle speed calibration. When a

two-speed axle is used, the change in gear ratios from

the high speed range to the low speed range alters the

calibration of the Vehicle Speed Limit and Vehicle Speed

Calibration, which require a calibration adjustment to

ensure the ECM-driven speedometer and ECM-stored

information correctly reﬂ ect the actual vehicle speed.

Available:

All electronically controlled on-highway engines

covered in this handbook

Range:

Engine

Range

Cat

Default

Minimum Maximum

Low

Speed

Range

High

Speed

Range

Low

Speed

Range

High

Speed

Range

3126E, C7, C9 0.00 0.00 19.99 9.99 0.00

C-10, C-12,

C-15, C-16,

C11, C13, C15

1.00 1.00 19.99 9.99 1.00

EPA’07 and

newer C7, C9,

C13, C15

1.00 1.00 19.99 19.99 1.00

Advantages:

Proper calculation of the Low Speed Range Axle

Ratio and High Speed Range Axle Ratio parameters is

essential for proper cruise control and speedometer (if

controlled by the ECM) operation, and accurate ﬂ eet and

driver trip data.

Disadvantages:

None

Recommendations:

✔ Let the OEM calculate the Low Speed Range Axle

Ratio and High Speed Range Axle Ratio parameters

based on the truck speciﬁ cations.

✔ Recalculate and program the Low Speed Range

Axle Ratio and High Speed Range Axle Ratio

parameters if any changes are made to the rear

axle ratios. Note that repairing or replacing the

rear end with the same axle ratio will not cause

a problem or require any recalculation for this

parameter.

Vehicle Speed Parameters
