Programming Cat Electronic Truck Engine Page 59

Programming
Page 58
PTO Confi guration
Description:
The PTO Confi guration parameter defi nes the features
that are available for dedicated PTO applications
and the input signals that the ECM monitors while in
PTO mode. The PTO Confi guration parameter has the
following programmable options:
OFF - indicates the application does not use
dedicated PTO
Cab Switches - indicates that the Cruise Control
Set/Resume Switch, in the cab, is being used
for control of Dedicated PTO function .
Remote Switches - indicates that control of the
Dedicated PTO function is outside the cab.
Remote Throttle - indicates that a Remote
Throttle is being used as part of the Dedicated
PTO operation.
Remote Throttle & J1939 Speed Command - indi-
cates that a Remote Throttle is being used as
part of the Dedicated PTO operation in addition
to the ECM monitoring the J1939 TSC1 Speed
Command.
Available:
All electronically controlled on-highway engines
covered in this handbook
Range:
Engine Range
Cat
Default
Pre EPA’07
Cab Switches,
Remote Switches,
Remote Throttle
Off
EPA’07 and newer C7,
C9, C13 & C15
Cab Switches,
Remote Switches,
Remote Throttle,
Remote Throttle & J1939
Speed Command
Off
Advantages:
The PTO Confi guration parameter allows the engine
to be easily customized to the many PTO application,
and reduces the number of mechanical components
required.
Recommendations:
✔ For the most recent information on PTO installation
and setup, refer to the PTO Application and Installa-
tion Guide RENR1282.
✔ If Dedicated PTO is used, all Dedicated PTO param-
eters must be programmed for proper operation.
Dedicated PTO Parameters
