Programming Cat Electronic Truck Engine Page 180

Programming
Page 179
Input Selection
Cruise Control Set Switch /
OEM
/
Description:
The Cruise Control Set Switch parameter is programmed
to identify the Cruise Control Set Switch connection
to the ECM. The switch itself is used in conjunction
with the Cruise Control On/Off Switch to control cruise
control operation when the vehicle is moving, to adjust
engine idle rpm when the vehicle is stationary, to adjust
engine rpm when the PTO Confi guration parameter is set
to Cab Switches, and to enable diagnostic fl ash codes
on the Check Engine Lamp.
Available:
All electronically programmable on-highway engines
covered in this handbook
Range:
Engine Alternatives Default
3126E, C7, C9
(PM MAR04 and after)
J1939 Body Controller, J1939
Cab Controller, J1939 Instru-
ment Cluster*
J1/P1:35
& 33
3126E, C7, C9
(PM MAR03 and
before)
C-10, C-12, C-15, C-16,
C11, C13, C15
J1939 Body Controller, J1939
Cab Controller, J1939 Instru-
ment Cluster*
J1/P1:35
& 44
EPA’07 and newer C7,
C9, C13, C15
None
J1/P1: 6, 7, 22, 23, 35, 40, 44,
45, 46, 47, 56, 58, 59, 60
OR
J1939 Body Controller,
J1939 Cab Controller,
J1939 Instrument Cluster
J1939 Cab Display
J1/P1:35
*Note: J1939 alternatives NOT available on PM OCT01 heavy duty
engines (C-10, C-12, C-15, C-16)
Recommendations:
✔ Make sure that the J1939 data link is available if
this parameter is programmed to one of the J1939
source Alternatives. Failure to do so will result in a
diagnostic code.
