Special Parameters
Customer Parameter Lockout
Description:
If a security level higher than a Customer Password(s)
(see page is required, either by the customer
or local laws, the following parameters can be
”locked out”.
• A/C Switch Fan-On Time
• Adaptive Cruise Control Enable
• Driver Reward Enable (C13 & C15 only)
• Coolant Level Sensor
• Engine Retarder Delay
• Fan Control Type
• Idle Shutdown Ignore Neutral Switch
• Low Cruise Control Speed Set Limit
• High Cruise Control Speed Set Limit
• High Speed Range Axle Ratio
• Low Speed Range Axle Ratio
• Soft Vehicle Speed Limit
• Torque Limit
• Transmission Style
• Top Gear Minus One Ratio
• Top Gear Minus Two Ratio
• Top Gear Ratio
• Vehicle Overspeed Threshold
• Vehicle Speed Calibration (J1939-ABS)
• Vehicle Speed Calibration (J1939-Trans)
• Vehicle Speed Calibration
• Vehicle Speed Limit
• VSL Protection
• Max PTO Vehcile Speed (Pre-EPA’07 Only)
• Top Engine Limiting(TEL) (Pre-EPA’07 Only)
These parameters have been labeled throughout this
book with the icon in the title bar.
Available:
All electronically controlled on-highway engines
covered in this handbook
Range:
Range Cat Default
Locked
Unlocked
Unlocked
Advantages:
The ability to lock certain critical parameters to comply
with either local laws or customer requests.
Disadvantages:
None
Recommendations:
✔ Lock only those parameters that are either required
by local laws or customer request.
221)
