Dedicated PTO Parameters
PTO Activates Cooling Fan
Description:
If the ECM is being used to run the engine cooling fan
circuit, this parameter can be programmed to have
the cooling fan cycle normally (based on Coolant
Temperature or Inlet Air Temperature or A/C High
Pressure) or run continuously when in the Dedicated
PTO Mode.
Note: The PTO Confi guration must be programmed to
Cab Switches, Remote Switches, Remote Throttle or
Remote Throttle & J1939 Speed Command before this
parameter can be programmed. The Fan Control Type
must also be programmed to On-Off or Three Speed Fan.
Available:
All electronically controlled on-highway engines
covered in this handbook
Range:
Range Cat Default
Normal
Continuous
Normal
Advantages:
Some applications require the fan to be on continuously
during PTO operation. This can be accomplished without
additional wiring by programming this parameter.
Disadvantages:
If the application does not require continuous fan
operation but the ECM is programmed to Continuous
mode, excessive fuel may be consumed, increasing
overall cost of operation.
Recommendations:
✔ Refer to RENR1282 for additional information.
