Programming Cat Electronic Truck Engine Page 111

Programming
Page 110
Idle Shutdown Timer Maximum RPM
Description:
The Idle Shutdown Timer Maximum RPM parameter is
only available if the Engine Idle System Confi guration is
programmed to Caterpillar.
The Idle Shutdown Timer is reset if engine speed
exceeds Idle Shutdown Timer Maximum RPM.
Programming this parameter to Top Engine Limit RPM
disables this feature and Idle Shutdown Timer cannot be
overridden by increasing engine RPM.
Available:
EPA’04 and newer C13 & C15 on-highway engines
EPA’07 and newer C7 & C9 on-highway engines
Range:
Engine
Range
Cat
Default
Minimum Maximum
EPA’07 and newer
C7 & C9
700 RPM 2640 RPM 2640 RPM
EPA’04 and newer
C13 & C15
600 RPM 2120 RPM 2120 RPM
Advantages:
May reduce accidental extended idle time if accelerator
is depressed.
Disadvantages:
None
Recommendations:
✔ Caterpillar recommends setting this parameter to
1000 RPM.
Timer Parameters
