Maintenance Parameters
PM1 Interval
Description:
If the Maintenance Indicator Mode (see page 131)
parameter has been programmed for either manual
mode; Manual-Distance or Manual - Hours, then the
PM1 Interval parameter must be programmed to the
desired miles or hours.
Available:
All electronically controlled on-highway engines
covered in this handbook
Range:
Manual - Distance
Range
Cat
DefaultMinimum Maximum
5000 Miles
(8050 km)
35000 Miles
(56325 km)
15000 Miles
(24140 km)
Manual - Hours
Engine
Range
Cat
DefaultMinimum Maximum
C-10, C-12,
C-15, C-16,
C11, C13,
C15
100 Hours 750 Hours 300 Hours
3126E, C7,
C9
100 Hours 750 Hours 250 Hours
Advantages:
By using either manual mode the owner will be notifi ed
of an upcoming PM interval based on his/her standard
interval.
Disadvantages:
The customer specifi ed PM interval may not be the
optimum maintenance interval. Maintenance intervals
based on older technology engines may be too short and
can raise the total cost of ownership.
Recommendations:
✔ Contact your authorized dealer for help in creating
customized PM intervals.
