Programming Cat Electronic Truck Engine Page 126

Programming
Page 125
Engine Monitoring Lamps
Low Coolant Level Lamp
OEM
Description:
The Low Coolant Level Red Stop Lamp is used to indicate
a low coolant level condition. The Low Coolant Level
Lamp default is not programmed. The Low Coolant Level
Red Stop Lamp can be used in conjunction with other
engine monitoring lamp options. The Low Coolant Level
Lamp is programmable to other ECM outputs.
Note: The Low Coolant Level Red Stop Lamp is
programmable between High Side (2 Amp) and Low Side
(Sensor Common) Drivers. Failure to properly program
and/or wire the lamp correctly could result in undesired
Red Stop Lamp operation.
Available:
EPA’07 and newer C7, C9, C13 & C15 on-highway engines
Range:
Engine Range Cat Default
EPA’07
and newer
C7, C9,
C13 & C15
High Side Drivers
(2 Amp Output)
J1/P1: 10, 11, 12, 13, 19, 20
Not
Programmed
Los Side Drivers
(Sensor Common)
J1/P1: 29, 30, 31
Note: Prior to 2007, the Low Coolant Level Lamp connection was
determined by the option chosen for the Engine Monitoring Lamps
confi guration.
Advantages:
Allows for dedicated lamp for driver notifi cation of low
coolant level.
Disadvantages:
None
Recommendations:
✔If Low Coolant Level Lamp is present, program
properly.
