Caterpillar GRADER, ROAD, MOTORIZED, DIESEL ENGINE DRIVEN (DED), HEAVY, COMMERCIAL CONSTRUCTION EQUIPMENT (CCE) OPERATORS MANUAL Page 8

OPERATORS MANUAL
TM 5-3805-261-10
f
WARNING
MACHINE OPERATION
• Use caution and maintain three-point contact at all times when mounting or dismounting machine. DO
NOT use steering wheel as a handhold. Failure to follow this warning may result in injury or death to
personnel.
• BE ALERT for personnel in the area while operating machine. Always check to ensure area is clear of
personnel and obstructions before moving. Failure to follow this warning may result in injury or death
to personnel.
• Use of seat belt while operating machine is mandatory. Fasten belt BEFORE operating machine. Trying
to fasten belt during operation creates a hazardous condition. Failure to follow this warning may result
in injury or death to personnel.
• DO NOT allow riders on machine. Failure to follow this warning may result in injury or death to per-
sonnel.
• NEVER leave operator compartment without applying parking brake. Failure to follow this warning
may result in injury or death to personnel.
• DO NOT use parking/emergency brake to stop a moving machine under usual conditions. Only if service
brakes fail, apply parking/emergency brake. Failure to follow this warning may result in injury to person-
nel or damage to equipment.
• NEVER use starting fluid or spray to aid in starting the engine, other than the on-board ether cold start sys-
tem. Failure to follow this warning may cause injury or death to personnel or damage to equipment.
• Always use a ground guide when driving machine up or down ramps in preparation for highway or marine
transport. Failure to use a ground guide may cause injury or death to personnel or damage to equipment.
WARNING
NBC EXPOSURE
• If NBC exposure is suspected, personnel wearing protective equipment must handle all air cleaner
media. Consult your NBC Officer or NBC NCO for appropriate handling or disposal procedures.
• Refer to FM 3-3, Chemical and Biological Contamination Avoidance, FM 3-5, NBC Decontamination,
FM 3-3-1, Nuclear Contamination Avoidance.
• NBC contaminated filters must be handled using adequate precautions and must be disposed of by
trained personnel.
To order this NBC decal use:
National Stock Number (NSN) - 7690-01-114-3702
Part Number (PN) - 12296626
Commercial and Government Entity Code (CAGEC) - 19207
WARNING
IF NBC EXPOSURE IS SUSPECTED ALL AIR
FILTER MEDIA WILL BE HANDLED BY PER-
SONNEL WEARING FULL NBC PROTEC-
TIVE EQUIPMENT. SEE OPERATOR/
MAINTENANCE MANUAL.
7690-01-114-3702
